液體噴砂機系列
◆企業產品優勢特點 Product features
1.巨大的調(diao)節了粉塵(chen)爆炸對(dui)大環境的的污染和對(dui)人工衛生(sheng)的導致;
2.業務策略具備靈活(huo)性高,加(jia)工(gong)技術參數可調,能轉變與眾不(bu)同于(yu)金屬材質和(he)與眾不(bu)同于(yu)高精(jing)度器件的光(guang)飾制作需求;
3.在運轉階段(duan)中金剛石工(gong)具(ju)巡(xun)環施用,所耗量小;
4.常見零組件在使用期限(xian)長;
5.橡膠鋼整殼(ke)生產制作,屏幕(mu)手表(biao)有防(fang)水能力防(fang)電經用。
1. Greatly improves the dust pollution to the environment and to workers health hazard;
2. The flexible methods work, process parameters variable, can adapt different materials and different precision components of light act the role ofing processing requirements;
3. In the process of operation abrasive recycling consumption, little;
4. The main components of long service life;
5. The plastic steel shell production, the waterproof and power and durable.
◆常用時間范圍 Applicable scope
電子元(yuan)器件(jian)五(wu)金工具類,ABSpp塑料,有機玻璃,樹酯等軸類或的手工作品的噴(pen)砂預工藝、啞光(guang)工藝、光(guang)飾(shi)工藝、快速(su)清理(li)污(wu)漬等。
Electronic hardware class, ABS plastic, acrylic, resin, or parts of the arts and crafts gush arenaceous pretreatment, dumb light processing, light act the role ofing processing, remove grease, etc.
◆主要方法性能 Main technical parameters
|
機械設備型號規格 Model |
STR-7070 |
STR-9060 |
STR-9070 |
STR-9090 |
STR-1200 |
|
機器大小 Complete machine size(mm) |
700×700×1750 |
900×650×1680 |
900×700×1850 |
900×900×1780 |
1230×1200×1850 |
|
辦公環境空間 Work space(mm) |
690×680×670 |
900×630×810 |
900×700×650 |
870×880×800 |
1220×1200×850 |
|
正門長寬高Main gate size(mm) |
530×330 |
550×650 |
600×670 |
630×700 |
975×660 |
|
噴 槍 Spray gun |
把 |
一回 |
一塊 |
二把 |
1把 |
|
照 明 Floodlight |
一盞盞60W防爆型燈 |
那盞60W防燃燈 |
一盞燈60W防爆型燈 |
一盞燈60W防爆設備燈 |
幾盞60W防爆型燈 |
|
砂 泵 Sand pump |
買臺,電功率1.5KW |
單臺,耗油率1.5KW |
這臺,瓦數1.5KW |
單臺,熱效率1.5KW |
一套,工作效率1.5KW |
|
電 源 Power |
單相電220V聯席會電 |
單相電220V座談會電 |
220V220V交流活動電 |
兩相電220V聊天電 |
三相變頻器220V交流會電 |
|
擠壓氣氛源 Compressed air source |
2-8bar(kg/m2) |
2-8bar(kg/m2) |
2-8bar(kg/m2) |
2-8bar(kg/m2) |
2-8bar(kg/m2) |
